Modern Luxury Double Entrance Gate with Hexagon Honeycomb Lattice & Vertical Slats – CNC Laser / Plasma Cut Vector Design (DXF / SVG / CDR)

Contemporary architectural double-leaf entrance gate vector design featuring vertical fluted slat sections, recessed vertical pull-handle posts with LED light channel provision, and side honeycomb hexagon lattice cut inserts. Production-ready for CNC fiber laser, plasma, and waterjet fabrication.

₹99₹49980% off
You save ₹400
Inclusive of all taxes
In stock
Easy Returns
Cash on Delivery
Genuine Products
Quantity
Order on WhatsApp
Share this product
Sold ByDxfkartView Store

Product Details

Give modern luxury homes and villas high-end curb appeal with this sleek, minimalist double gate vector fabrication package. Designed specifically for metal workshops, architects, and laser cut specialists, this layout combines continuous vertical acoustic/fluted line tubing profiles with a geometric honeycomb (hexagonal) pattern strip on both leaves.

The package includes full cut files for the laser-cut hexagonal side strips, layout drawings for the vertical tubular slat arrays, and mounting details for long vertical pull handles with warm backlighting channels. All vector paths are 100% closed, pre-bridged, and engineered for clean cutting and easy assembly into rectangular hollow section (RHS) perimeter frames.

  • File Formats Included: DXF, DWG, SVG, CDR, AI, EPS, PDF

  • Included Vector Elements:

    • Full 2-Leaf Symmetrical Gate Layout (Left & Right leaves)

    • Vertical Hexagon Honeycomb Lattice Cut Insert Panels

    • Precision Spacing Slat/Flute Fabrication Layout Blueprint

    • Center Handle Plate & Backlit Channel Template

  • Recommended Materials: Mild Steel (MS) sheet/box pipe, Aluminum, Stainless Steel (Grade 304), or WPC/HPL backer boards

  • Recommended Sheet Thickness: 2.0 mm to 4.0 mm for laser/plasma cut honeycomb panels; frame fabricated with standard 50×50 mm or 40×80 mm steel box tubing

  • Scalability: 1:1 scale; easily rescalable in AutoCAD, CorelDRAW, or LightBurn to match custom villa entry openings (e.g., 10×7 ft, 12×8 ft, 14×8 ft, 16×8 ft)

  • Applications: Villa main swing/sliding gates, modern residential entrance gates, estate security gates, luxury compound perimeter barriers

  • Digital Download: Instant production-ready vector download; zero overlapping paths or open nodes
