A contemporary screen pattern that mixes organic circle overlaps with a precise central rosette. The Greek key border frames the pattern neatly, and the open geometry gives excellent light and airflow. The layout is a tall panel suited to doors and partitions.

File Formats Included: DXF, DWG, SVG, CDR, AI, EPS, PDF

Included Vector Elements / Layout:

  • Overlapping circles and ovals of varied sizes
  • Concentric ring details
  • Central circular rosette with Greek key ring and radiating spokes
  • Greek key outer border

Recommended Materials: Mild steel, stainless steel, aluminium, MDF, acrylic, plywood

Recommended Thickness & Assembly: MS 1.6 - 2 mm, aluminium 2 - 3 mm, MDF / plywood 12 - 18 mm. Reinforce with a frame; keep minimum bridge width in mind for thinner materials.

Scalability: 100% vector artwork that can be resized to any door, gate or panel size without loss of quality. Scale in your CAD/CAM software, then check kerf, minimum bridge width and cut-out spacing for your material and machine before cutting.

Applications: Jali screens, room dividers, door panels, balcony and window grills, ventilation panels

Digital Download: Instant digital download after payment. Clean, closed vector paths with no overlapping nodes or duplicate lines, ready for laser, plasma, waterjet and CNC router toolpaths. This is a digital design file only. Handles, hinges, locks, frames and other hardware shown in the preview images are not included.
