Modern Double Entrance Gate with Greek Key Border & Transom – CNC Laser / Plasma Cut Vector Design (DXF / SVG / CDR)

Give residential and commercial entrances an upscale architectural presence with this complete double-leaf gate vector cut package. The design features layered Greek key (meander) linear border frames surrounding an intricate central floral medallion with ventilation louvers, capped by a matching ornamental top transom grille.

Engineered specifically for metal fabricators and CNC workshops, this file contains fully closed vector contours and structural bridge tabs to eliminate dropouts, optimize piercing paths, and ensure simple assembly into rectangular or square hollow section (RHS/SHS) steel tubing.

• File Formats Included: DXF, DWG, SVG, CDR, AI, EPS, PDF

• Configuration: Complete 2-door symmetrical layout (Left Leaf + Right Leaf) plus top decorative transom section

• Recommended Materials: Mild Steel (MS), Stainless Steel (SS), Galvanized Iron (GI), Aluminum, or Exterior HPL/WPC decorative boards

• Recommended Sheet Thickness: 1.5 mm to 4.0 mm for cut sheet inserts, easily welded or fastened into box pipe frames

• Scalability: 1:1 vector scale; easily rescalable in AutoCAD, CorelDRAW, or LightBurn to fit custom door openings (e.g., 6×7 ft, 7×7 ft, 8×8 ft, 8×10 ft with transom)

• Applications: Main residential gates, villa double front doors, courtyard security doors, compound wall entrance gates

• Digital Download: Instant production-ready vector file; zero open contours or overlapping nodes
