Diagonal Chevron Floral Lace Jali Gate Design - Laser Cut Double Door with Transom | DXF / SVG / CDR
Product Details
A rich, layered gate design. Diagonal chevron and diamond frames create a strong geometric structure, filled with fine floral lace jali. The arched transom carries a repeating lace band for a complete, cohesive front.
File Formats Included: DXF, DWG, SVG, CDR, AI, EPS, PDF
Included Vector Elements / Layout:
- Interlocking floral lace jali pattern
- Diagonal chevron and diamond frames with brass strip borders
- Repeating floral lace transom band
- Double door with fixed side panels
Recommended Materials: Mild steel, aluminium, stainless steel, brass strips for edging
Recommended Thickness & Assembly: MS 1.6 - 2 mm, aluminium 2 - 3 mm. The fine lace pattern needs a backer sheet; weld or bolt to a rigid frame.
Scalability: 100% vector artwork that can be resized to any door, gate or panel size without loss of quality. Scale in your CAD/CAM software, then check kerf, minimum bridge width and cut-out spacing for your material and machine before cutting.
Applications: Main gates, grand entrances, villa gates, commercial entrances
Digital Download: Instant digital download after payment. Clean, closed vector paths with no overlapping nodes or duplicate lines, ready for laser, plasma, waterjet and CNC router toolpaths. This is a digital design file only. Handles, hinges, locks, frames and other hardware shown in the preview images are not included.
Product images are for reference. Actual colour may vary slightly across screens.
